Share your 4G LTE network with multiple Wi-Fi devices
Enjoy download speeds of up to 150Mbps
Wireless N speeds of up to 300Mbps
Integrated antennas provide stable wireless connections
Requires no configuration - just insert a SIM card and turn it on
Share Your 4G LTE Network
Take full advantage of your cutting-edge 4G LTE network with the TL-MR6400, which can achieve download speeds of up to 150Mbps. The TL-MR6400 allows you to share your 4G LTE network with multiple Wi-Fi devices so you can enjoy uninterrupted HD movies, rapid file downloads, and video chats that won't freeze up.
300Mbps Wireless Speed
The 4G LTE router provides the 300Mbps Wi-Fi connections that you need for online gaming, HD streaming video, ultra-fast downloads. The integrated antennas allow you to enjoy stable wireless connections and excellent wireless coverage.
No Configuration Required
With an integrated 4G LTE modem and a built-in SIM card slot, all you need to do insert a SIM card and turn the router on. Enjoying fast, stable Wi-Fi on a 4G LTE network has never been easier.
Wi-Fi Where You Need It
The TL-MR6400 offers unmatched convenience and versatility. It provides the perfect solution in any situation, from relaxing at home to working in a remote location, just plug it in to boost on-site productivity and stay connected in a diverse range of environments. From the exhibition center to the RV, the TL-MR6400 has you covered.
Backup WAN Port Keeps You Connected
With the inclusion of the WAN/LAN port, the TL-MR6400 can also support a wide variety of connection types, including cable, fiber, and DSL modems
|
|
HARDWARE FEATURES
Interfaces:
3 10/100Mbps LAN Ports, 1 10/100Mbps LAN/WAN Port, 1 SIM Card Slot
Button :
WPS/Reset Button, Wireless On/Off Button, Power On/Off Button
External Power Supply:
12V/1A
Dimensions (W X D X H):
7.95 x 5.55 x 1.32 in. (202 x 141 x 33.6 mm)
Antenna Type:
2 Internal Wi-Fi Antennas, 2 Detachable External 4G LTE Antennas
Wireless
Wireless Standards:
IEEE 802.11b/g/n 2.4GHz
Frequency:
2.4GHz
Signal Rate:
300Mbps at 2.4GHz
Reception Sensitivity:
11g 54M: -74dBm
11n HT20: -71dBm
11n HT40: -67dBm
Transmit Power:
CE: <20dBm(2.4GHz)
Wireless Functions:
Enable/Disable Wireless Radio, WDS Bridge, WMM,
Wireless Statistics
Wireless Security:
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions
Network Type :
4G: FDD-LTE Cat4 (800/900/1800/2100/2600MHz)
TDD-LTE (2300/2600MHz)
3G: DC-HSPA+/HSPA+/HSPA/UMTS (900/2100MHz)
2G: EDGE/GPRS/GSM (850/900/1800/1900MHz)
Software
Quality of Service:
Traffic Control(IP QoS)
Operating Modes:
3G/4G Router, Wireless Router
Management:
Access Control, Local Management, Remote Management
WAN Connection Type:
Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access)
DHCP Server, Client, DHCP Client List, Address Reservation
Port Forwarding:
Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS:
DynDns, NO-IP
VPN Pass-Through:
PPTP, L2TP, IPSec
Access Control:
Parental Control, Local Management Control, Host List, Access Schedule, Rule Management
Firewall Security :
DoS, SPI Firewall, IP Address Filter/Domain Filter, IP and MAC Address Binding
Protocols :
Supports IPv4 and IPv6
Guest Network:
2.4GHz guest network x 1
Others
Certification:
CE, FCC, RoHS
Package Contents:
300Mbps Wireless N 4G LTE Router, TL-MR6400
RJ45 Ethernet Cable
Power Adapter
Quick Installation Guide
Micro to Standard SIM Card Adapter
Nano to Standard SIM Card Adapter
System Requirements:
Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, MAC OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 browsers or higher, or other Java-enabled browsers
SIM Card
Environment:
Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
|
